Review: The Leica D-Lux 6/ Panasonic LX7

March 25, 2013 By Ming Thein 105 Comments

There aren’t that many choices for fully-featured, pocketable compacts at the moment; in my ongoing quest to find the ideal take-everywhere companion, I’ve probably tried most of them. Current top of the heap is the Sony RX100; I’ve also used the GR-Digital series, Fuji XF1 and Panasonic LX/ Leica D-Lux series. For whatever reason, I’ve never really bonded with the Canon S-series, so that’s never made it into my pocket; same with any of the Nikon Coolpixes, though I’m really hoping the A will change that. Whilst I loved the RX100 for its fantastic sensor, the lens arguably lets the package down: it may be fast one the wide end, but for it to keep up with the sensor in the corners, you have to stop down a bit (thereby negating this advantage) and the tele end is just plain slow.

[Read more...]

Filed Under: Gearhead: Reviews, Leica Tagged With: compact, gearhead, leica, leica d lux 6, ming, mingthein.com, panasonic lx7, point and shoot, review, thein

Lens review: The Leica 35/1.4 Summilux-M ASPH FLE

February 28, 2013 By Ming Thein 45 Comments

I couldn’t find a product shot in my archive, so you’re going to have to settle for one of me using it instead.

Not long after this lens was initially released and generally available – early 2012 – I published a guest post review here on the Leica Blog. At that point, I’d had no more than a couple of weeks to shoot with the lens, and certainly not under any kind of duress or pressure. Since then, I’ve both encountered many situations with the lens and used it as pretty much the go-to on my M9-P in the hopes of making 35mm one of the intuitive focal lengths in my repertoire. It didn’t stick, and somewhere in the middle of last year, I landed up selling it to one of my students.

Diner. All images in this review shot with the Leica M9-P except where otherwise noted.

I’ve been meaning to do a full review for some time now, but the reality is that there have been many other things which have gotten in the way – or perhaps I should stop making excuses for being lazy.

The 35mm f1.4 Summilux-M ASPH FLE is version seven in a long and distinguished line of lenses – some may even think of them as legendary and quintessentially Leica. They’ve grown larger, heavier and more expensive as time moved on – earlier versions were practically pancakes compared to the 35 FLE, but admittedly they were also relatively poor performers at maximum aperture. The previous version (VI) featured a single aspherical element (there was a very rare double aspherical version produced too, relatively early on in the life of this lens) and was known for being both an excellent optic, but hamstrung by one huge flaw: focus shift.

[Read more...]

Filed Under: Gearhead: Reviews, Leica Tagged With: 35 1.4 asph fle, gearhead, leica, lens, ming, ming thein, mingthein.com, review, summilux, thein

The 2013 Leica M Typ 240

February 22, 2013 By Ming Thein 226 Comments

Previously in October 2012, I had a chance to handle the M Typ 240 (I’m going to call it the M 240 from hereon in) back at the Kuala Lumpur launch event, and produce a quick preview (that can be found here). At that point, the camera was a very early functioning prototype – yet the improvement over the M9 was clear. There was of course no way to get images onto a PC for review; the SD card was glued in and the grip had no USB ports. Frustratingly, things appeared pretty good on the new (and larger) rear LCD. But we all know that such small and limited-gamut monitors are not a good way to determine image quality at all; I was thus itching to get my hands on a camera, or at very least, some good files to play around with. I’m not really a fan of long waits to availability – whilst it’s nice to know what’s in the works, I’d rather not have to wait six or more months before I can actually buy one. By then, the world might just have moved on.

[Read more...]

Filed Under: Gearhead: Reviews, Leica Tagged With: 2013, gearhead, leica, m, m system, m typ 240, ming, ming thein, mingthein.com, review, thein, typ 240

Review: The Ricoh GR1v

February 16, 2013 By Ming Thein 35 Comments

Earlier at the start of this year, I was lucky enough to have not one, but two of the cameras I lusted earlier in my photographic career show up – the Contax T3, reviewed here, and the Ricoh GR1V, which is the subject of this article. My first encounter with the GR1 was in 2001, when I was a student and there was still an independent pro camera store on Oxford’s High street. I was looking for a compact point and shoot and played with just about everything they had to offer, but landed up being seduced by something small and horrible (an APS Fuji Tiara 1010i, of all things). The GR1 (or perhaps it was a GR1v) was the only one that left much of an impression due to the way it felt, and the rather stiff price tag. Later, I recall a time in late 2005 or early 2006 when I visited a local camera store – at that point I was very much in the acquisition phase (not that it ever really stopped) on the hunt for exotic old lenses; the faster the better because I was still dealing with the limitations of the D2H. They had the Ricoh GR-Digital in stock, and the GR1V too – I landed up handling both, once again very much liking the feel of the GR1V, but walking out with the GR-Digital.

[Read more...]

Filed Under: Film Diaries, Gearhead: Reviews Tagged With: film, film diaries, gearhead, gr1v, ming, mingthein.com, review, ricoh, ricoh gr1v, thein

Review: The Contax T3

February 14, 2013 By Ming Thein 52 Comments

First, a starting note. Reviewing film cameras both takes a little longer and always somehow feels a little less complete than doing the same for digital; I suspect it’s because there really are quite a lot of unknowns in the equation which you can’t determine whether are due to the camera or some other portion of the process. Still, there are definitely characteristics that shine through regardless – part of this is perhaps down to the equality of media across all cameras – an F6 has the same sensor as a Mju II, which in turn has the same sensor as a 1930s Leica I. Differences are down to glass, assuming that processing is carried out consistently. When evaluating images in the analog domain, it’s already difficult enough to form an opinion based on a small websize jpeg; this is why it’s important to go along with the words of the reviewer as they’ve (hopefully) seen large, uncompressed files on a calibrated monitor – what you’re seeing is merely for illustration and perhaps to break up the enormous blocks of text. The same goes for film: a web scan isn’t going to have anywhere near the same amount of information as the original negative; even printing introduces an additional variable into the mix which might lead a review to conclude erroneously.

[Read more...]

Filed Under: Film Diaries, Gearhead: Reviews Tagged With: contax t3, film diaries, gearhead, ming, ming thein, mingthein.com, review, t3, thein, tilm

Quick review: CarrySpeed DS-2 sling strap

February 5, 2013 By Ming Thein 41 Comments

_5016081 copy

Full disclosure upfront: I was recently sent a couple of interesting camera straps by the folks at CarrySpeed/ Kroxmedia – the DS-2 is of the sling variety and has a fixed portion that goes diagonally around your shoulders as shown in the image above, and a sliding loop that holds your camera and allows it to rest around waist level, or be easily brought up to shooting position. There are quite a lot of similar products, which I’ve not really been too enamoured with for a couple of reasons: firstly, the camera connection point doesn’t have a quick release, which means that if you need to take it off or stow it, it’s not easy to do so; secondly, the hardware just doesn’t inspire confidence.

The DS-2 doesn’t have the second problem. It’s a very well made strap; perhaps over engineered in some ways – I feel there are just too many plastic loops and buckles through the webbing portion – but the thick neoprene padding with non-slip backing is certainly appreciated and spreads out the load nicely. There’s also a quick release buckle to allow you to detach the strap completely, which has a safety interlock to prevent accidental release and expensive crunching noises.

_5016086 copy

The first problem is partially solved on all models through the use of a ball and locking threaded socket connector; the former screws into the tripod socket of your camera, and the latter is fixed to the strap with a metal loop. It’s easy to attach and detach when needed, but not easy to accidentally detach – and the locking screw has to be fully undone before the ball releases, which is a good half a dozen turns. If you’re a tripod user, there’s an optional Arca-compatible quick release plate whose ball swings out of the way when mounting; unfortunately, no joy to those of us who are stuck with the enormous 410PL plates Manfrotto uses on its geared heads.

Try as I might, I couldn’t find a way to get comfortable with this strap on my (mostly) tripod-based Nikons; it simply isn’t designed for that. However, I did find that it seemed to work best used on the Hasselblad 501C – where it now lives – because most of the time I shoot this handheld, and it simply isn’t comfortable around the neck or easy to swing into position when worn over one shoulder. The heavier weight of the camera helps to anchor it in place and stop it from moving around too much, too. I admit I was a bit nervous putting this much weight on the connection at first, and held a hand under the camera to cradle it in case it fell; I’ve since become much more comfortable and it now pretty much swings around freely. There’s one other little bonus I’ve discovered: the plain little knob-shaped quick release is useful for two things: firstly, on the Hasselblad, it helps me stabilize the camera because I’ve got somewhere to hook a finger around; secondly, it’s useful as a mini-monopod cum-ballhead when resting the camera on a table – just take it off the strap and use a hand to support it.

There are some cameras I probably wouldn’t use it on though – the smaller mirrorless cameras might swing around a bit because they’re not big enough or have lenses long enough to stay in place against your body; and be a bit careful with the digital Leica Ms, because their baseplates are not known to be the strongest – especially the small metal lip that hooks over the opposite end to the locking nut…

In short: if you’re looking for a sling-type strap, the CarrySpeed DS-2 does the job nicely. It’s a good product for street photographers and people who want to have the option of using both hands but at the same time have a camera in a comfortable quick-draw position. MT

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from Amazon.comhere. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: camera strap, carryspeed ds2, gearhead, ming, ming thein, mingthein.com, quick review, thein

Lens review: The Nikon AFS 60/2.8 G Micro

February 1, 2013 By Ming Thein 63 Comments

In what appears to be a hideously enormous oversight on my part, I seem to have neglected to review what is ostensibly my most used lens: the Nikon AFS 60mm f2.8 G Micro-Nikkor. As you might expect, I use this lens for the majority of my commercial watch photography. I prefer it over the 85 PCE for images that require high magnification, as this lens natively reaches 1:1 magnification on its own; thus requiring fewer extension tubes to reach even smaller levels of frame coverage.

Nitro Experiment One

Before we start talking about the lens specifically, I would like to debunk some myths about macro vs micro photography: both have to do with the reproduction ratio created by the lens on the imaging medium; it is format independent. Simply, macro refers to 1:1 or greater magnification (i.e. a 20mm wide object in reality would be 20mm or wider when projected on the sensor plane); whereas micro refers to magnification slightly less than this but more than would be encountered during normal photography – ‘close focus’ might perhaps be a more accurate term. Almost nobody seems to get this right online, even the manufacturers; ‘macro’ mode almost never yields 1:1 magnification, and there aren’t that many lenses that achieve this natively. (I suppose Carl Zeiss gets away with it by sounding German and putting a ‘k’ in Makro-Planar – these are 1:2 lenses.)

Water on slate

The 60/2.8 G replaces its predecessor, the 60/2.8 D, both of which are 1:1 lenses; unlike its predecessor, it reaches 1:1 through internal focusing alone, and the lens doesn’t extend – the front element on the G is a lot closer to the front of the barrel, and as a result, offers greater working distance at a given magnification than the D (which has a very heavily recessed front element). The lens has been completely redesigned with a new optical formula; it’s a 12/9 design with aspherical and ED elements, as well as Nikon’s Nano Crystal Coating. It also has a silent wave motor, but no focus distance limiter (oddly, the older version did have this). Focusing is fast and silent, but occasionally the lens does get ‘lost’ – if you’re say at the near focus limit and point it a subject at infinity, then sometimes it can hunt and fail to find focus. A quick tweak of the focusing ring solves this. One thing I have noticed with all of the Nikon SWM macro lenses is that they appear to be very ‘nervous’ when focusing at close distances; they’ll chatter and hunt and rack back and forth slightly. This could be because I’ve got the camera in AF-C most of the time, but it doesn’t really make sense given that everything is static – camera on tripod, inanimate subject. Still, I haven’t noticed any focusing errors, even on the D800E; in fact, this lens is the only one I’ve got that doesn’t require AF fine tune correction on any of my cameras.

Cigar

I also owned the previous version of this lens, and the difference mechanically is night and day; optically, somewhat less so, but the newer version is clearly better. (I suspect part of the reason why the G appears sharper is simply because it can focus more accurately without any of the backlash inherent to screwdriver-focusing lenses.) The biggest difference in optics between the two version are seen in off-center performance – specifically to do with CA – and bokeh. The new lens has very little lateral chromatic aberration; you have to be shooting something very, very contrasty and bright to excite it. For most subjects and shooting conditions, you probably won’t see any lateral CA at all. Longitudinal CA is a different matter – whilst again better than the old lens (and much better than the 105/2.8 VR), longitudinal chromatic aberration is still visible, as are traces of spherochromatism. It’s not a disaster, but it does mean that some work has to be done in postprocessing to remove traces of this – especially on say, white metal watches. On the bokeh front, the new lens has a 9-bladed, perfectly round aperture diaphragm that makes for very smooth out of focus areas; amongst the best I’ve seen, actually – though at normal distances, a 60/2.8 will not yield a huge amount of separation.

Alphabet pasta

It’s worth noting that the lens’ maximum effective aperture at 1:1 is about f4.8; this isn’t because it’s a variable-aperture lens, but rather because additional magnification always results in some light loss. The Nikon lenses and bodies are the only combination that reports this correctly – not that it matters, because the meter takes care of any necessary exposure adjustments anyway. I suppose it might be important if you were to calculate flash exposure with guide numbers, but I can’t think of anybody who still does that.

On the subject of flash, shooting into the light yields no problems at all; the Nano-coated element is clearly doing its job when it comes to suppressing flare. (I use partial backlight quite often to clean out backgrounds or help define the texture in watch dials.) Macro-and micro-contrast are both very good, improving slightly on stopping down. I feel this lens has a bit more microcontrast ‘bite’ than overall global macro-contrast; this isn’t a bad thing at all as it helps to extend dynamic range somewhat.

Breguet La Tradition

I actually don’t have much to say about resolution and optics: what do you expect? It’s a macro lens. There’s almost zero distortion or field curvature, and nothing funny going on with the focal plane. Sharpness is already excellent at f2.8, though with the D800E you’ll probably have to go to f4 or f5.6 to hit peak resolving power across the frame. Note that diffraction softening will set in by around f13 or so with the D800E; I try not to go past f16 unless I absolutely have no choice. That said, you can get away with f22 on the 12MP FX cameras if you need to.

Something I’ve been asked in the past is why I don’t use the 105/2.8 VR instead for greater working distance; the answer is that for the kind of work I do, the 60 actually holds several advantages. Firstly, I don’t need as many extension tubes to achieve higher magnifications*; secondly, the lens itself has much lower chromatic aberration than the 105 – lateral is fairly well controlled on both, but longitudinal is ugly on the 105 – and requires a lot of work to fix afterwards. Finally, there’s the issue of depth of field: for any given aperture, you’ll get more with the shorter focal length**. And given that you’re already challenged to find enough as it is, I’ll take any advantage I can get.

Who could resist a steak like that?

*The more mounts you put between your optics and your camera, the higher the chance of something going out of plane.

**A longer focal length does not mean that you can stop down more before diffraction sets in; that’s a property of the sensor’s pixel pitch, not the lens.

Of course, for those situations when I really need to manipulate depth of field, there’s the 85/2.8 PCE Micro – note it’s a Micro lens, because it only reaches 1:2 – and its full array of movements. That – and an accompanying piece on the Scheimpflug effect and how to properly use a tilt-shift lens – will be the subject of another article.

Girard-Perregaux F1-047

For the work I typically do with macro lenses – watches and food – the pairing of 60/2.8 G and 85/2.8 PCE is usually more than sufficient to deal with any possible scenario. If you shoot bugs, or want the lens to do double-duty for portraits, the 105 is probably a better choice; that’s not to say that the 60 can’t do the job; it just won’t give you the working distance or depth of field control you’d like to have. (The optics remain similarly excellent at longer distances – you could quite happily use this as a long normal lens if you didn’t mind the slowish f2.8 aperture; it out resolves all of the ‘regular’ 50 1.4s and 1.8s I’ve used, especially in the corners.) Perhaps the most telling fact I can leave you with is that of all of the lenses I own, it’s the one that’s been with me the longest. MT

The Nikon AFS 60/2.8 G Micro is available here from B&H and Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: 60/2.8 g micro, gearhead, lens, macro, ming, ming thein, mingthein.com, nikon, review, thein

Lens review: The Olympus ZD 12/2

December 27, 2012 By Ming Thein 43 Comments

Although this lens is not new – in fact, it was announced back in 2011 with the second-generation E-P3, E-PL3 and E-PM1 (full review here) – it still remains ostensibly the best fast wide option for Micro Four Thirds users. (It was also recently re-released as a limited edition all-black version, which now includes the lens hood as part of the kit.) In fact, there’s been remarkably little competition in this arena – just a manual focus offering or two from SLR Magic, and the upcoming (and stratospherically priced) Schneider 14/2.0. Panasonic has the 7-14/4, and the 14/2.5; the latter which is perhaps the 12/2’s closest competition.

My initial experience with this lens and its optics on the E-P3 and E-PM1 were enough to convince me that Micro Four Thirds had come of age, and would make a worthwhile compact system without major compromises for the majority of situations in which I’d want to use a compact system camera. This impression held, wavered, and changed again – to be honest, until the last Tokyo workshop, I hadn’t had much of an opportunity to use the 12/2 on the OM-D (full review here) for a serious evaluation. The last time I used the lens on the OM-D was also the first time I’d taken out the camera for a serious bout of shooting, and definitely wasn’t a good way to benchmark performance of either camera or lens – simply too many variables and unknowns were in play here.

Spiral. E-PM1, ZD 12/2

The lens is one of the Olympus Super High Grade line, impeccably built and finished with all-metal construction, and one unique feature (for a Micro Four Thirds Lens) – the focusing ring clutch. Sliding the focusing ring backwards a notch puts the lens in manual focus mode, and also reveals a focus distance scale: unlike every other lens in the system, the 12/2 has hard stops at each end of the range. Together with the depth of field scales, the lens should theoretically be the ideal tool for street photography – fast, wide, zone-focusable, and with more depth of field for a given aperture and field of view than its 35mm equivalent.

In AF mode (left) and scale-focus MF mode (right)

Except, this isn’t quite the case. Sadly, the clutched focus system isn’t really mechanically linked to the position of the lens elements; it too is a fly-by-wire simulation – albeit a very good one, with the right amount of tactile feedback and everything. The problem is to do with the resolution of the distance scale/ mechanism: there aren’t enough divisions.

Reflections, Tokyo. OM-D, ZD 12/2 from a moving train

It seems that there are perhaps five or six discrete distances to which the focusing group moves, instead of a continuum. The only thing that could cause this is if Olympus used a form of rheostat in the construction of the the focusing ring/ clutch. Although 12mm is a very wide actual focal length with plenty of depth of field for a given aperture, f2 is fast enough that more critical control over your focus point is required. Sadly, though the idea of the ring is a good one, the execution makes it of marginal utility for the photographer in the real world – unless you are willing to use a small aperture – f4-5.6 or smaller – to use depth of field to cover the lack of manual focus precision.

Diagonals, Shibuya. OM-D, ZD 12/2

Curiously, this is most definitely not the case for either manual focus with the ring in the AF position (i.e. selecting manual focus on the camera body) or when using autofocus. Here, the lens is precise, moves in as many infinitesimally incremental steps as one could desire, and has no trouble finding critical focus. While on the subject of focusing, it’s probably a good time to talk about autofocus performance. Like all of Olympus’ other MSC designs, the 12/2 is an extremely snappy lens – even more so on any of the recent bodies. I haven’t experienced any gross focus misses, but it’s worth noting that some care is required at f2 – the plane of focus isn’t quite as deep as you’d think.

Taxi rush, Shinjuku. OM-D, ZD 12/2

The lens is not weather sealed or gasketed, and once again, Olympus has decided not to include a hood – this is excusable for a $250 economy kit item, but not on a $800 premium lens. It just smells too much like penny pinching. Perhaps it’s just as well, because the optional hood is rather cumbersome; it increases the bulk and visual size of the lens hugely, requires a thumb screw to attach, can rotate freely and requires a different cap – why can’t they just use a bayonet hood? Zeiss lenses are a great example of how bayonet hood mounts should be constructed.

Shadows, Otemachi. OM-D, ZD 12/2

Over a good year of use with this lens on the E-PM1 and OM-D, those are my only two complaints: the inaccuracy of the pseudo-manual focus clutch, and the continued minor farce of the lens hood. If you read this carefully, it means that I don’t have any major criticisms of the optics.

The 12/2 uses a rather exotic optical design with 11 elements in 8 groups; one of these is aspherical, one is made of ED glass, and another two of exotic Super HR and DSA glasses. It’s a non-symmetric, telecentric design whose optical formula honestly doesn’t look familiar to me – the closest thing I can think of are the Zeiss Distagons, insofar as they use several extremely dome convex front elements and a rear telephoto group. The lens also employs Olympus’ ZERO coating to minimize flare and maximize contrast and transmission.

The overhang. OM-D, ZD 12/2

Let’s get the most popular question out of the way first: yes, it’s sharp. Bitingly so, at all apertures, across the entire frame in all but the most extreme corners. There appears to be a small amount of field curvature, but nothing overly serious; enough that for optimal sharpness you’ll want to move the focus point over your subject rather than using center-focus-and-recompose, though. The lens has a slightly odd MTF chart that is indicative of a significant dropoff in microcontrast about halfway to the edges; I don’t see this in practical use, which suggests that the field curvature is probably responsible – and more complex than a merely spherical surface. In the real world: sharpness will not be an issue.

Fuji TV building, Odaiba. OM-D, ZD 12/2

Though some of you might think that a little nice bokeh might be obtainable from the 12/2, you’d be mistaken; you have to be very close indeed to throw anything significantly out of focus. Fortunately, the lens focuses down to 0.2m, so this is actually possible. If you have enough distance between subject and background, then bokeh is actually fairly pleasant; however, if there isn’t a lot of distance, and the subject is a bit farther away from the camera, nothing really gets out of focus enough to begin with – in fact, you have to be a bit careful of double images in the out of focus areas. There’s a bit of spherochromatism, too.

Star. OM-D, ZD 12/2

Although the lens in general well corrected, you do get the feeling that it’s on the extreme edges of what was possible with the design constraints put upon the optical designers: there’s visible CA against high contrast subjects, especially in the corners where you can get up to 2 pixels’ worth; there’s also very noticeable distortion. Fortunately, it’s fairly simple in nature – barrel with no sombrero/ moustache – and is easily correctable in ACR. Flare exists but the ZERO coating does a good job of keeping it to a minimum – even without the hood. Stopping down to f4 on the OM-D makes everything but the distortion go away, leaving you with an excellent optic. It doesn’t quite have the transparency of the 75/1.8 or 60/2.8 Macro, but it’s fairly close if used stopped down. It is definitely the best wide option for M4/3 users at the moment. One interesting use of the lens is for handheld long exposure photography – due to the short focal length and excellent stabilizer in the OM-D, shutter speeds of anywhere down to 1/2s (consistently) or 1s (occasionally) with critically sharp results are possible, making for some interesting photographic opportunities.

Commuters. OM-D, 12/2

As always, I suppose the litmus test for a lens is if you’d buy it a second time – I think the answer for me would be a qualified yes. I have since had the chance to shoot with the Panasonic 14/2.5; thought I prefer the 28mm field of view over 24mm, and believe that M4/3 lenses should be a compact as possible to play to the other strengths of the system, I would still pick the 12/2 as the optics are better – they simply render in a more three-dimensional way due to better microcontrast, as well as better edge sharpness. Interestingly, the Panasonic 12-35/2.8 runs it very close at f2.8; however, the T stop of that lens is about 1/3-1/2 stop slower too, for a given physical aperture. What qualifies my opinion is the upcoming Schneider 14/2; it remains to be seen if it performs as well as its price suggests it should. In the meantime, the best way to judge the 12/2 is on its pictorial results – construction, expensive accessories and the imprecise focus clutch are just distractions. And on that basis alone, I think the lens deserves a place in a serious M4/3 shooter’s bag. MT

The Olympus M.Zuiko Digital 12/2 is available here from B&H and Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: 12/2, gearhead, lens review, m4/3, micro four thirds, ming, ming thein, mingthein.com, olympus, review, thein, zd 12 2, zuiko digital

Lens review: The Voigtlander Color-Skopar 28/2.8 AI-P SLII

December 7, 2012 By Ming Thein 37 Comments

The small, light Nikon D600 got me thinking about full frame as a viable alternative for a lightweight travel kit again – the D700 and f1.4 primes was smaller than a D3 and pro zooms, but certainly nowhere near as convenient as Micro Four Thirds. Of course, M4/3 doesn’t give you anywhere near the same control over depth of field, and you lose out at least a stop or more in high ISO performance. The OM-D might give you back a couple of stops of hand-holdability thanks to its excellent stabilizer, but there’s nothing you can do about depth of field control short of using the manual focus Voigtlander f0.95 lenses – they certainly fit the bill, but they’re also large, heavy and somewhat defeat the point of a small, light body.

Shadows

This is where the pancake primes and full frame come in: a D600 body and two primes make for a very light but also very competent travel kit. And if you shoot film, it makes even more sense. (And naturally, being a 28mm lens, I was curious to try it out.) The 28/2.8 has ridden shotgun in my waist pouch when I go out with the F2T and 58/1.2 Noct; sometimes you just need something wider, and it’s a handy option to have without paying too high a weight/ size penalty.

Untitled

The lens is just 24.5mm long (in Nikon F guise; it’s also available in EF mount, which is slightly larger as it has to accommodate the electronic diaphragm components) and weighs a scant 180g; it actually feels reasonably hefty as the entire lens is metal – probably anodized aluminium – and is very well constructed. It’s actually so short that it’s tricky to mount without turning the focusing or aperture rings, as the only portion of the lens that doesn’t rotate is the tiny 3mm wide section in the middle that holds the depth of field scale and index mark. It would have been great to have a locking button on the aperture ring like the ZF.2 lenses, but I suppose Cosina reserves that function for its more expensive siblings.

Urban monk

Being an AI-P spec lens, the 28/2.8 has a chip to communicate aperture and distance information to the camera; you set the lens to f22 on a Nikon body and control the aperture using the command dials as normal. It will mount and provide full metering and electronic compatibility on any Nikon body. Focusing is manual, of course; would have been nice if there was a way to AF couple the lens – a built-in motor would probably have been impossible, but screwdriver focus might have been within feasible limits. That said, you always have the built-in rangefinder and in-focus confirmation dot (or beep on Canons) to help with determining focus, and the manual focus action is nicely damped and perfectly weighted – they certainly got the feel right with this lens. Since the lens is relatively slow and wide, it isn’t always easy to judge focus by the viewfinder alone – and Nikon’s modern focusing screens don’t help much, either. Most of the time, I could get achieve focus with the viewfinder alone, but on the edges it helps to use the dot: the lens suffers from moderate field curvature.

Shifty

The 28/2.8 is a 6-group, 7-element design; Voigtlander does not provide a block diagram or any details about the optical design, but from the way it performs and the fact that it can focus as close as 22cm from the sensor plane – yielding surprisingly high magnification – I suspect that the lens is a retrofocal but non-telecentric design to achieve this. As mentioned earlier, it displays moderate field curvature, some coma at the edges and chromatic aberration until f8 or so. (I tested the lens on the Nikon D600.) There’s also a tiny bit of purple bleeding at high contrast edges.

Through the looking glass

Sharpness is not a problem: the center is excellent at all apertures, with the border and edges lagging until about f5.6 or so; this is partially due to field curvature, and partially due to coma. Note that if you’re going to use wide apertures with this lens, you will need to use focus assist over the subject – not center focus and recompose. Edge sharpness is not too bad, but the corners never get critically sharp due to radial coma/ smearing; you always feel that things have been ‘stretched out’ a little. No problem; just make sure your subjects are within the central portion of the image circle.

Umbrellas

Not having a huge number of elements, color rendition and contrast are excellent; images are rendered with a slightly warm hue, high saturation and macrocontrast. Microcontrast still isn’t as fine as the Zeiss lenses, but it’s certainly on par with Nikon’s regular AF offerings. This would be a good lens for low contrast scenes, but care must be taken if you’re shooting around noon in the tropics – you’re going to get things blocking up to black or overexposing if you don’t pay attention to your blinking highlights warning. It makes a rather good lens for black and white work, too.

The morning after the night before

I consider myself a bit of a 28mm aficionado; perhaps fetishist is a better word. I find that it’s the widest I can go and still maintain a relatively natural look to the images without the usual wideangle geometric distortion; I feel that the focal length also matches my instinctive field of view quite well. This means that in my time I’ve owned and shot with a huge number of 28mm lenses and 28mm equivalents; the two I currently own – the Nikon AFS 28/1.8G and Zeiss ZF.2 2/28 Distagon are reviewed on their respective links, too. Aside from that, I’ve also got the Zeiss ZM 2.8/28 Biogon for my Leica M9-P, the 28/1.8 equivalent on the RX100, the iPhone 4, and an Olympus 15/8 body cap.

Texture

So the natural question would be where does the Voigtlander 28/2.8 fit in – both in the grand hierarchy of 28mm lenses, as well as as a tool; I actually think it has a pretty well-defined niche. The Nikon 28/1.8 G is large but light, has autofocus and pretty good optics; the Zeiss 2/28 Distagon has stellar optics and a unique pictorial rendering, but is manual focus and surprisingly heavy for its size. Both have roughly the same maximum aperture and T stop. The Voigtlander is a tiny slip of a lens that’s capable of excellent results in the center, and decent results at the edges – these optical characteristics suggest it would serve as a good documentary lens (there is some distortion of straight lines which rules it out for architecture), but moreover an option where you a) need something light and small, and b) are unlikely to run out of light – though relatively low light work is still possible thanks to the high-ISO abilities of the current batch of full frame cameras. In short: this is a great lightweight travel lens, especially if paired with something a bit longer – perhaps the 40/2 or 45/2.8P. Now, if only somebody would make a decent focusing screen for the D600…MT

A big thank you to Eric Goh at Fotoman Marketing, the Malaysian distributor for Voigtlander lenses for the extended loan of the review sample.

The lens is available here from B&H in Canon and Nikon mounts.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: 28 2.8, ai-p, d600, gearhead, lens review, ming, ming thein, mingthein.com, nikon, thein, voigtlander

Twenty questions

November 27, 2012 By Ming Thein 45 Comments

I get a lot of email every day. Hundreds of messages are pretty common, actually. And a lot of those emails ask the same questions over and over, so I thought to save time for both myself and any prospective writers, I’d address some of these openly here. Firstly, thank you for all of the feedback, compliments and interesting discourse; I’m less appreciative of the long lists of ‘what should I buy’ questions: firstly, if you’re not specific in your question or give insufficient context and information, I can’t give you a recommendation – ‘i want to take nice photographs what camera should I get?’ is far more common than you might think (and punctuated that way, too). Secondly, the same basic courtesy that you’d give to somebody in person is appreciated over the internet, too. Whilst I do make an effort to reply every email I get, I’m seriously thinking about ceasing replies to rude and demanding people. Time is precious. An hour spent giving camera advice is an hour out of pursuing client leads or postprocessing commercial work or family time.

So, in no particular order:

1. What camera should I buy?
It depends on what you want to do with it, but is also completely irrelevant. If you know what you’re doing – and the fact that the question was asked at all in the first place indicates that you probably do not – then the camera doesn’t matter at all. If size is a priority, then look at the Sony RX100. If size and image quality/ flexibility, then the Olympus OM-D. If kids or moving objects, a midrange DSLR like the Nikon D7000 or Canon 7D would work. If it’s image quality, then buy a tripod, some good prime lenses and the Nikon D800E. Frankly though, any of the cameras you can buy today at each of the levels – prosumer compact, mirrorless, entry DSLR, pro DSLR – are all far past the point of sufficiency for most users; those who require more will already know they require more. In the right hands, any of them can give great results. Education matters far more than equipment.

2. What lens should I buy?
Same question: what are you going to use it for? And even if you know what you’re going to use it for, what’s your style? A National Geographic reporter will use a 21mm for environmental portraits. A paparazzi will use a 400/2.8. Both are therefore portrait lenses. See the problem?

3. I have X. If I upgrade to Y, will it give me better pictures?
No, unless you’ve identified a specific deficiency with X that is improved with Y; and in every case, spending money – or just time – upgrading your skills will have far more of an impact than upgrading your camera.

4. Why haven’t you reviewed X/Y?
Firstly, this is a photography site, not an equipment review site. There is a difference; there are few good and plenty of mediocre sites devoted to being the first to fondle new metal. I acknowledge that the two are frequently inseparable because photography is a pursuit that is heavily influenced by one’s equipment, but I still think it’s important to know if you’re an equipment masturbator or a photographer. There is a difference. In most cases, I have to buy my review units with my own money. This means that I’ll only review things that are interesting to me, and I even if I do find them interesting, they’re only available when they’re available to buy. Sometimes, if I’m very lucky, I’ll get a loaner. I don’t review systems/ brands that aren’t familiar to me because I don’t have the experience required to do them justice and write a fair review, nor the time or interest to learn. Finally, I’m usually strapped for time. Running this site is secondary to being a commercial photographer – gotta pay the bills somehow.

5. How can I improve my photography?
This question is surprisingly rare. Firstly, it deserves a commendation just for asking. Practice is the number one thing; getting feedback is number two. Though it’s possible to figure out yourself over time what works and what doesn’t, the process can be made much faster by finding a good mentor – that could be your friends or peers, or me via the Email School. Don’t be afraid to experiment, but make sure you know what you changed and how it affected your picture. Look at lots of other people’s images to get an idea of what elements you like, and what you don’t; shoot some more and try it for yourself. Learn how to use Photoshop if you haven’t already; it’s like the difference between sending film to a minilab and using whatever auto-everything presets they’re using, or developing it yourself, frame by frame. Or perhaps eating McDonalds vs Michelin star – with the same ingredients.

6. How can I order your DVDs?
Firstly, the whole DVDs or individual segments (they’re recorded separately with different source images) are available online via my iPad app. Secondly, if you don’t have an ipad or would prefer a physical DVD, send US$60 (Intro to Photoshop Workflow for Photographers) or US$65 (Photoshop Flow for the Leica M-Monochrom) via paypal to mingthein2@gmail.com along with your address and phone number for the shipping. Thirdly, if you don’t have paypal, send an email to mingthein2@gmail.com and I’ll send over a credit card checkout link. Fourthly, if you live in Kuala Lumpur and would like to collect the DVD in person (COD) or pay via MEPS, send me an email. Thanks!

7. Do you have any upcoming workshops/ I’d like to register my interest for workshops
Yes; here’s late 2012/ 2013, dates TBC:
~~November 2012 – Introduction to wildlife, Kuala Lumpur – 1 day (late November, been and gone)~~
Feb 2013 – Possibly Kathmandu (5 days – 4 shooting, 1 review after days 2 and 4.5)
April 2013 – USA Tour: San Francisco, Boston, New York (possibly New Orleans too). Each 3 days – two of shooting, one of photoshop.
September 2013 – Europe Tour: London, Barcelona, Munich (possibly Prague too). Each 3 days – two of shooting, one of photoshop.
Please send an email to mingthein2@gmail.com to put your name on the list. Each workshop is limited to 8 participants at the absolute maximum. If there’s demand, I’ll do two sessions. More information on past workshops can be found here

8. Is the D800 focusing issue fixed?
To the best of my knowledge, the new cameras I’ve handled recently do not exhibit this problem. There is a fix at Nikon for older cameras that involves recalibration of focus bank data; it’s a firmware only procedure and does not require disassembly or physical adjustment of the camera (at least that’s what I’m told).

9. On a related note, should I upgrade from my APS-C/DX/D700 to the D800?
Only if you know you need the resolution. That’s the biggest gain, really. Do you frequently print larger than 20×30″? Are your images tack-sharp at the pixel level? What about your postprocessing technique? If the answer is no to any of those three, then go back and make the most of what you’ve got first. The D800/ D800E are capable of amazing quality, but also utter crap if not used with the utmost shot discipline.

10. What about D600 vs D800?
I’d throw D700 into the mix too. If speed/ sport are a priority, then D700. Low light is a wash between D700 and D600; what you gain from the D600′s slightly cleaner sensor and lower vibration shutter is taken away by the increased shutter speed requirements due to higher resolution. If ultimate image quality is your aim, then get a D800E – but make sure your lenses, support and computer are up to the task.

11. What cameras/ lenses/ flashes/ tripods are you using now?
In alphabetical and numerical order below. What I use is of course also what I’d recommend.
Gitzo GT5562 GTS Systematic with Manfrotto 410 geared head, or 468MGRC0 Hydrostatic ball head
Gitzo GT1542 Traveller with Gitzo 1780QR head
Leica M9-P
Nikon D600 (backup), D700 (reportage/ low light), D800E (primary for commercial work), F2 Titan (personal work)
Nikon AFS 28/1.8 G, AI 45/2.8P, AI-S 58/1.2 Noct, AFS 60/2.8 G, AFS 85/1.8 G, PCE 85/2.8
Nikon SB-700 x1, SB-900 x3
Olympus OM-D
Olympus ZD 12/2, ZD 45/1.8, ZD 60/2.8 Macro
Panasonic 20/1.7, 100-300/4-5.6
Zeiss ZF.2 2.8/21 Distagon; ZF.2 2/28 Distagon; ZF.2 2/50 Makro-Planar; ZF.2 2/100 Makro-Planar; ZM 2.8/28 Biogon; ZM 2/50 Planar

12. Do you have a favorite bag?
It depends on what I’m doing. I use a Billingham Hadley Pro as a day bag for a laptop, a camera and lens or two; a Think Tank Airport International as my assignment bag alongside a couple of large Manfrotto lighting grips/ tripod bags; a Kata LPS-216 DL for travel, or an assortment of Think Tank and Lowepro waist pouches for reportage work. There is no perfect solution here.

13. I’m using X/Y/Z filter, why can’t I get my images to look like yours?
Simple: filters are presets. And since every image is different, the presets will apply perfectly to precisely none of your images. The only way to get images that look like mine is by using my workflow – which requires photoshop optimization for each image individually. Perhaps a DVD would help…

14. How do I get my images to look like yours?
See #13.

15. Could you please critique my images/ comment on my Flickr/ Facebook stream?
If you want me to do it in a way that’s actually useful for you as a photographer, then I suggest you sign up for one of my detailed portfolio reviews or the Email School – send a message to mingthein2@gmail.com for more details. By the way, Facebook is a really crappy way of looking at images because of the compression and terrible color space (probably as an artefact of compression, actually).

16. Do you teach watch photography?
For practical and commercial competition reasons, no. It requires a lot of demonstration, some custom-built equipment, advanced Photoshop skills, and it doesn’t make any commercial sense to train potential competitors – especially when what I can bill for training is a small fraction of commercial work.

17. Do you shoot weddings/ events/ parties/ etc?
You obviously have not read any of what I’ve written otherwise you’d know what the answer would be. Though I’ve been asked so many times that perhaps I should consider it…

18. Great photo! Can I use your image for…[insert something here]
I am a commercial photographer. This means I make my living from selling images. If you’d like to license it for commercial use, I’m happy to discuss rates. If you are linking for another site, it depends. If you are just using it for your own site, definitely not. But whatever the case, please ask first and give the appropriate usage credits. You wouldn’t go into a bakery and say ‘hey, nice pastries, could I take one for free if I’m just going to display it a bit but not eat it?’

19. Ever think about doing something (writing, etc) related to film?
Yes, but that’s going to take some time both because it’s film and because it’s been a while since I last shot film. But there’s a reason why I’ve now got an F2 Titan loaded with Delta 100.

20. How do you find the time to do everything you do?
We make the time for the things we enjoy. So long as I enjoy photography and writing, this site will continue to go on much in the same way it has in the past. When that changes, then I’ll probably suddenly find that I require a lot more than the four or five hours of sleep I’ve been subsisting on for most of this year. MT

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: On Photography Tagged With: gearhead, ming, ming thein, mingthein.com, popular questions, Q&A, thein

Lens review: The Nikon AF-S 85/1.8 G

November 23, 2012 By Ming Thein 45 Comments

The Nikon AFS 85/1.8 G (released at the start of this year) is a slightly odd product. Unusually for Nikon, the new version doesn’t cost a lot more ($50, give or take a bit) than the old one; doubly unusually, it isn’t a warmed-over cosmetically-modified version, either. (It’s also now made in China, which might have something to do with it. The old lens was made first in Japan, and then Thailand since 2010.) The 85/1.8 D was a simple double Gauss design with 6 elements in 6 groups; the new one uses a 9/9 optical formula. The elements in front of the iris ostensibly retain the double Gauss formula, but everything afterwards is new. As far as I can tell, the same basic optical principles apply, except every single element in the rear group has been replaced with an achromatic doublet of sorts; not a true achromatic doublet because there’s an air gap between neighbouring elements.

Images from Nikon USA. The D is on the left, the G is on the right. Note far more complex rear group; the pairs of lenses do effectively the same thing as the single lenses in the earlier design. The images are to scale, too – note increase in size. It doesn’t seem to be any heavier, though – and noticeably lighter than the 85/1.4 G.

This complex formula has two benefits: firstly, lower chromatic aberration because there’s that extra element there for correction; secondly, internal focusing is now possible (the previous design focused by moving the entire optical assembly back and forth, like all double-Gauss designs). As far as I can tell, the front and rear elements (possibly more than one) are fixed, and the rest move back and forth. At this point, it’s worth noting that unlike Nikon’s newer optical designs, it’s remarkably free of any exotic technology – whilst the bottom of most lenses now play host to entire essays in abbreviations about Nikon’s lensmaking prowess, the 85/1.8G is remarkably clean. All it has is internal focusing and the silent wave motor – that’s it. There’s no Nano-crystal coating, no ED glass (let alone Super ED glass) and no aspherical elements. Even the new 50/1.8 G employs asphericals!

Untitled. Nikon D800E

Regular readers of my site will know that I was originally a huge fan of the 85/1.4 G, especially on the D700 for it’s sharpness, quality of bokeh and incredible ability to shoot into direct light sources with minimal to no flare. You’ll also know that despite trying multiple samples, I was never quite happy with the performance of this lens on the D800E; mainly due to lateral chromatic aberration wide open, and so-so edge performance. It’s therefore logical to assume that there are optical quality reasons as to why I’m now using the 85/1.8 G instead. You’d be right.

Caution. Nikon D800E

In all of my A-B testing with similar subjects, several samples of both lenses – the 85/1.8 G was consistently sharper in the center at f1.8, let alone f1.4. it’s possible that real resolution was identical, however, the 85/1.4 G showed so much lateral chromatic aberration that it robbed the images of perceptual acuity. It was also sharper at the edges – markedly so, especially on the D800E. It’s worth remembering that at f1.8, the 85/1.8 G is wide open, and the 85/1.4 G is 2/3rds of a stop down. Granted, it’s easier to design a good slower lens than a faster one, but then again, the 85/1.4 G has a huge amount of technology in it – aspherical and ED elements and Nano-crystal coating, for starters. Interestingly, the optical formulae for both lenses are nearly identical.

Apprehension. Nikon D800E

Bottom line: the 85/1.8 G is sharp at every aperture, across the frame, even on the D800E – providing you nail the focus, of course. There is remarkably little falloff in sharpness from center to edge; consistency and microcontrast improve marginally to f4, but it’s already outstanding by f2.8. I only shoot this lens wide open, which should give you some indication of how I feel about the optics. Chromatic aberration under normal situations is almost non-existent; a remarkable performance. Even though this lens has 7 blades instead of the 9 of its predecessor (and 85/1.4 G), bokeh remains pleasing, neutral and smooth. I’ve yet to see any odd artefacts like double imaging or nervousness, but there is a tiny bit of spherochromatism (color fringing) in the out of focus areas. In fact, it’s one of the better-rendering lenses I’ve used in this regard. Color transmission is neutral, per the current crop of Nikon lenses; though the saturation is unsurprisingly not as high as the Nano-crystal equipped optics.

Phonecall. Nikon D800E

You’re probably wondering what the tradeoff is, given the huge gulf in price between the 85/1.4 G and 85/1.8 G; the last line should have given you a clue. It has to do with contrast, saturation, transmission and flare. It seems that the Nano-crystal coating makes an enormous difference to all four; the 85/1.8 G takes a noticeable hit in every area compared to the 85/1.4 G (it still improves on the old lens in every way, however). The problem stems from flare; when you have extraneous light bouncing around inside the lens between elements – a good coating minimizes reverse reflections off air-glass surfaces – everything else suffers. The most obvious manifestation of this is under backlit conditions, of course – especially when there is a bright point light source in the frame. The 85/1.4 G shows almost zero flare; the 85/1.8 G gives an enormously spectacular trail of reflections off what appears to be every single element. This can be pleasingly cinematic for atmosphere or video work, except the lens has no hard infinity stop, which makes focus pulling challenging. For stage/ performance work, it’s a pain in the ass. Unfortunately, the supplied hood makes no difference simply because it can’t block light from entering the front of the lens – and it’s these rays that are causing the problem.

Ugly flare – and this is after correction by burning and desaturation. Nikon D800E

Internal flare also lowers contrast; macrocontrast especially. Microcontrast is a bit worse, but not by much. By f2.8 both lenses are neck and neck here. The knock on effect is a reduction in overall saturation; no surprises here. Perhaps the least obvious, and most surprising side effect is a huge reduction in transmission (read my article on the difference between T stops and f stops for more detail). At any of the wide apertures, the 85/1.8 G transmits between 1/2 and 2/3 stop less light than the 85/1.4 G; this is to say that if both are set to a physical aperture f2, then you’ll find the 85/1.8 G’s required shutter speed for a given exposure to be noticeably lower than the 85/1.4 G. In other words, if you set 1/100s f2 ISO 200 on both lenses, the 85/1.8 G photo will be underexposed by 1/2-2/3 stop. The reason is because a lot of the light entering the lens isn’t making it to the sensor plane, thanks to suboptimal coatings.

That said, it’s still better than the old lens.

Less ugly, more cinematic flare – but still flare. Nikon D800E

The new lens gains a silent wave motor and loses an aperture ring; it’s still plastic, but now the crinkle-finish variety to match the modern bodies and lenses. The plastic type appears a lot less brittle than the 85/1.8 G, though admittedly I’ve never had issues with any of the older lenses other than a propensity to pick up scratches easily. The silent wave motor isn’t any faster than the screwdriver method; it’s about the same, actually – especially on a body with a high voltage built in motor like the D3 or D4. The difference is in precision: it’s a lot easier to move a coreless linear motor in the small increments required to adjust for small changes in focusing distance than a geartrain with associated backlash. In practical terms, you’ll find the new lens a lot more precise than the old one. (It still remains useless if you use an older camera that requires an aperture ring.) The lens also gains environmental gaskets, making it a good choice for pairing with a similarly sealed body.

Solo. Nikon D800E

I thought that it would be easy to write a conclusion to this review; it isn’t quite so straightforward. I’m going to turn it around a bit instead:

Buy the AFS 85/1.8 D if:

You shoot with a manual focus camera, or want to use the lens both on your Nikons and other systems via an adaptor – otherwise you’ll have no aperture control.
This lens is optically inferior to both of the G versions, and not much cheaper than the AFS 85/1.8 G.

Buy the AFS 85/1.8 G if:

Resolution at maximum aperture and CA are important, i.e. you shoot with a D800/ D800E.
You want lower contrast because you shoot with an older, lower dynamic range body
Size and weight are important; the lens is noticeably lighter and a bit smaller than the 85/1.4 G.
Price is important
You like cinematic flare.

Buy the AFS 85/1.4 G if:

You need as much light gathering ability as possible, or shoot frequently under very low light conditions
You shoot into bright point sources a lot
You shoot with a lower resolution body
Notice I haven’t mentioned bokeh yet: the 85/1.4 G is slightly better than the 85/1.8 G, but it doesn’t justify the increase in cost.

The Nikon AFS 85/1.8 G is available here from B&H and Amazon; the AFS 85/1.4 G is available here from B&H and Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: afs 85 1.8 g, gearhead, lens, ming, ming thein, mingthein.com, nikon, nikon 85/1.8 g, review, thein

Review: The Fuji FinePix XF1

November 13, 2012 By Ming Thein 80 Comments

One of the more interesting compacts in recent memory is the Fuji Finepix XF1. Announced at Photokina 2012, it’s a pocketable metal-bodied camera with a moderately sized sensor – not the 1″ of the Sony RX100, but not the usual 1/1.7″ type either. It shares a sensor with the Fuji X10 – the 12MP 2.3″ EXR-CMOS, presumably it’s the updated version without the white orb issue; I certainly didn’t see any during my testing. The camera is definitely retro-styled, with a faux-leather skin covering the middle portion of the body, with warm silver metal covers top and bottom – presumably anodized aluminum. It’s certainly a pleasingly tactile object to handle. For the style conscious, the camera is available with black, tan or red pleather; I opted for red since the camera was ostensibly a present for my wife.

The camera’s biggest party trick is its lens: a 25-100/1.8-4.9 equivalent that both sports a mechanical zoom ring – slowly becoming a rarity even for M4/3 cameras – and a collapsing mechanism that lets it drop back into the camera body to keep things pocketable. Presumably it’s an evolution of the design used on the X10, though obviously not as fast due to size constraints. Again, like the X10, it also powers on the camera. One twist into standby mode puts the camera either into ‘ready’ position (if enabled, eats battery); another twist to the wide end of the zoom turns the camera on. I would love to have a separate power switch, too – this would make it a fantastically responsive camera as you could have the desired focal length preset before powering on; something I wish the otherwise very fast Sony RX100 could do.

Lens in a range of positions from fully retracted to fully extended.

Needless to say, zooming is quick and easy. The mechanism itself is reasonably smooth, but it could use a bit more damping to give a higher quality feel; you have the impression of a lot of light pieces of plastic or thin metal moving around inside the lens barrel as you turn it. In fact, the camera is quite light – generally a desirable quality – personally, I’d prefer a bit more heft. Finally, stiffer detents between the 25mm position, STANDBY and OFF would help avoid accidental power ups/ shut downs. The only other notable mechanical gubbin is the release lever for the dinky pop-up flash hidden in the top plate.

It would seem that the feature race hasn’t ended for the enthusiast-level compacts; the XF1 is packed with all sorts of modes and customisability; the only three that are of any real note are the dynamic range optimiser, built in level and customizable buttons. The former does some strange things with the sensor and ISO range to extend highlight and shadow dynamic range in JPEG files only; it seems to work. I’ll say more on this in the image quality section. The built in level is an unobtrusive horizon line through the middle of the frame that works for roll only, but shows a single green line when the camera is level. It’s actually quite handy on a camera of this size, because it isn’t always easy to hold it stable with one hand – not that you’re going to be shooting the XF1 singlehanded with the mechanical zoom.

Traffic. Fuji XF1

Finally, there are effectively no less than seven programmable buttons: pressing E-Fn brings up a virtual overlay where the user’s choice of shortcuts are assigned to the four directions of the D-pad, playback and record buttons on the back; there’s also another function button on the top plate behind the shutter. Annoyingly – perhaps out of muscle memory – it’s in exactly the same place as the power button on just about every other compact, and I find myself repeatedly hitting it and wondering why the camera won’t turn on or off, but instead bring up a menu. The only function which I’d want to assign to this direct-access key (you don’t have to press E-Fn first) would be AF area – and guess what, this also happens to be the only one of the customizable functions that’s missing from the list of possibles for this button. Grr.

Yard abstract. Fuji XF1

It’s worth noting that there is no way to separate AE lock and AF lock from the shutter button – so the half-press-and-dance routine may result in some undesirable metering. The XF1 also has a lens-shift based image stabilization system that moves a group of four elements. The best word to describe it is ‘aggressive’; it reminds me of the early days of IS where the image would sway a bit as the stabilizer locked down. I’m estimating it’s probably good for 2-2.5 stops. It certainly isn’t as effective as the Panasonic OIS system, which I think is probably still the class leader for compacts.

Camouflage. Fuji XF1

Overall, there are a lot of things I like about the UI, and a number I don’t. Playback is done well, for a change on a compact – you can power on the camera straight into playback mode by holding down the play key; there’s no need to extend the lens. Then, press in the top command dial in to go to maximum magnification, and then you can compare images at the same zoom level and position by moving the rear dial. But this is where another issue raises its head: the camera has two command dials, which is the same number as any camera of this size and most pro DSLRs. Yet by default they seem to be dormant or redundant most of the time – only in M do the two dials do anything independently. It would be sensible to have one serve as direct acesss to exposure compensation and the other as program shift/ aperture/ shutter speed in the other modes, but no. You have to press up on the D-pad to enter exposure compensation, then use either dial to change it. And then press up again to go back to changing the main exposure setting. Still, at least it’s a shooting priority camera. It just seems that there are a lot of wasted opportunities here that would have let Fuji knock one out of the park with this little camera’s handling. There’s still hope for a firmware update, I suppose – Ricoh’s GRD series is very much the leader when it comes to compact camera handling; and it’s done with no more buttons than the XF1 has.

Trash alley. Fuji XF1

Other little things – the LCD isn’t the highest resolution out there, with about 460,000 pixels; you can just about make out the pixel mask if you look closely, but most of the time it’s a non-issue. The screen gets pretty bright for daylight use, but of course that comes at the expense of battery drain. I’d like to see something a bit less contrasty, though; it doesn’t give that good an indication of overexposure – but there’s a blinking highlights warning in playback mode to get around this. Fortunately, the XF1 seems to be fairly miserly with power consumption, yielding about 300 frames on a charge of it’s quite physically small battery. The lens-based on-off switch makes it quite easy to power the camera off between frames, which of course helps with battery life. The camera also shoots full HD video at 1080p30, which is nice but not something I use – so I’ll leave it to others to test.

Urban geometry around dawn. Fuji XF1

I was not impressed with its predecessor’s focusing speed – despite having ostensibly the same sensor and a faster lens, the X10 is not a fast-focusing camera. This isn’t the main problem, though – it freezes between half-press and achieving focus, which means that a) if you move slightly, and you will because it’s a compact, then you won’t see it until you get a sudden jump when the camera focuses; b) the delay is annoying. In fact, this was the main reason why I didn’t buy one. I’m pleased to report the XF1 fixes this. Whilst there’s still a very tiny perceptible freeze, it’s almost negligible. I certainly don’t notice it in practical use.

Untitled. Fuji XF1

Overall; the XF1 is a fast camera and doesn’t keep you waiting. It shuttles around RAW or JPEG files with equal indifference, except perhaps write time is noticeably longer. That said, I wouldn’t recommend using this camera to shoot RAW even though it can; and this has a lot to do with the quality of the in-camera processing, and the absolutely crappy results obtained via ACR. This is a bit of a shame, as the lens quality is very impressive – better than the Zeiss-branded lens on the Sony RX100. It doesn’t suffer from the same flare or low contrast at wide angle and f1.8; the corners are also much sharper. More impressively, this level of optical quality is maintained through the telephoto end of the range, too. (It could also be because the lens has to cover a much smaller image circle than the RX100′s.) There is some CA in the corners, but flare is impressively low, microcontrast high, and color rendition pleasing.

Spot the dent. Fuji XF1

Despite Fuji’s claims about the camera’s bokeh-generating ability (and 7-bladed diaphragm) – the reality is that you’re only going to get a tiny bit of background separation if your subject is close, you’re shooting at 25mm and f1.8 equivalent, and the background is very far away. The RX100 has more potential for subject isolation through shallow(er) depth of field, and I still treat that as a program mode-hyperfocal camera. As with every small-sensored camera, don’t bother with aperture priority: you have no control over depth of field anyway. I only use program and manual – either when the built in flash triggers speedlights, or in the case of the XF1, you need exposure times longer than a second – and remember to disengage auto ISO first, otherwise you can’t go any slower.

Nature outgrows us all. Fuji XF1

I find the image quality of this camera paradoxical. On one hand, the JPEG output is amongst the best I’ve ever seen from a compact – especially when using the trick DR400 mode, which supposedly extends the camera’s tonal range by two stops – on the other hand, the RAW files are amongst the worst I’ve ever seen from any camera, and far below even its own JPEGs. The RAW files are far noisier, have poorer dynamic range, less detail and acuity, and just seem very dull by comparison; it’s akin to the difference between RAW and JPEG on other cameras, except in reverse. The only conclusionS I can come to are that Fuji has some extremely sophisticated processing algorithms inside this camera, the ACR converter algorithm just doesn’t work for this sensor, or both. It is widely known that ACR doesn’t really do a good job with Fuji files, but this difference almost defies belief. Needless to say, ~~I’m not going to be using RAW mode on the XF1~~ it will be set to JPEG DR400 mode for my wife to use. For the purposes of this article, I shot JPEGs and did some minor tweaking to them with Photoshop.

What on earth is going on here? That’s not a mistake: the DNG (converted via ACR 7.2 from the original Fuji Raw file) is on the right. Full size file here.

All that said, the image quality of the JPEGs is superb. Noise is low, detail is high (though oddly blocky in places, somewhat reminiscent of the older SuperCCD designs) and the tonal rolloff in the highlights is outstandingly well handled. Note that you really do have to use the DR400 mode to achieve this; otherwise the highlights blow just as fast as with any other compact. The files just look natural. The files actually remind me strongly of the 6MP SuperCCD FinePix F10, F11 and F30/31fd cameras; perhaps this is their spiritual successor. Of course, if you want there are also the usual super-saturated, B&W and toned modes; Fuji labels them with the names of its film – Provia, Velvia, Astia – though I doubt any of the XF1′s buyers even know what those things are, let alone what they should look like.

JPEG noise crops. Full size here.

RAW (via ACR) noise crops. They just simply look worse than the JPEGs. Full size here.

On the noise front, I would have no qualms in using this camera up to ISO 800 in JPEG mode; 1600 and 3200 are noticeably softer, but surprisingly close in terms of both noise and detail retention. Thus, 3200 is probably a viable option in emergencies. Fuji does a pretty good job balancing noise reduction and detail here. Dynamic range noticeably decreases when you increase ISO, note that in order to expand dynamic range, the camera increases the ISO. This is presumably to allow additional sensitivity in the shadows. Yet the camera is smart enough to only increase the ISO past the sensor’s base of 100 if it detects that the dynamic range of the scene exceeds the sensor’s native capabilities – neat. This is why you might see EXIF data for a photo in good light with ISO 400 – it’s a wide dynamic range scene – or ISO 100, if the contrast levels are manageable. Note that you do see a bit of noise in the shadows at DR400 mode, but at least they’re not blocked up to black.

DR modes do make a noticeable difference. Note the garlic at the bottom; the leftmost image is DR100 (i.e. standard) mode; the right, DR400. Full size crop here.

Confusingly, Fuji makes the DR AUTO, DR100, DR200 and DR400 modes available both in the full-resolution 12MP mode, as well as on a separate EXR position on the mode dial. Here you can choose for dynamic range, resolution or low light priority; I don’t see the point unless you’re not going to do any processing afterwards at all. I suppose it must be a kind of smart auto mode, though there’s also the camera position, ADV(anced) and scene modes on the dial – how on earth does this many options make things less confusing to the camera’s intended audience, or more useful to the advanced user who just wants a good compact? Personally, I’m leaving it in P mode and DR400. If I want lower noise by pixel binning, I can do that myself afterwards in Photoshop – the results between the 6MP SNR (EXR Low Noise) mode and a downsized 12MP file in P mode look pretty much the same to my eyes. What Fuji should have done is made an auto mode that maintains best perceptual image quality: in good light, shoot at 12MP, say up to ISO 800; in high contrast situations, automatically use DR400; finally, when the required ISO goes to say 1600 or above, then start binning pixels down to 6MP.

Bigger onions. Fuji XF1

So where does the XF1 stand against the other competition in this segment? In the same price and size bracket, we have the Panasonic LX7/ Leica D-Lux6; the Canon S110, and the Sony RX100 – though the latter is a bit more expensive. All are moderately pocketable. I’ve excluded the Nikon P7700, Canon G15 and Olympus XZ2 because I don’t think these are pocket cameras anymore. I’ve not used the Canon extensively, so I’ll refrain from commenting on that; it and the LX7 both use a smaller sensor than the XF1, and it shows. The Canon is perhaps at the greatest disadvantage because it has the slowest lens and the smallest sensor; the XF1′s image quality – certainly the JPEGs – are noticeably better. The LX7 has a lens that’s fast at both ends and optically excellent, which claws back some of the Fuji’s sensor advantage; it also has more isolation potential as the long end of the lens isn’t f4.9. I’ve always liked the LX series as macro cameras too; they focus very close throughout the entire zoom range, not just wideangle. This leaves us with the RX100: it on the other hand isn’t a very good macro camera at all because the lens performs poorly at close distances until f4 or so; and doesn’t focus close throughout the rest of the range. However, it does have the best sensor of the lot; clearly a notch above the Fuji, and challenging Micro Four Thirds. I wouldn’t use the Fuji at ISO 1600 and very low light; I’ve done higher ISOs with the Sony and still gotten pretty impressive results.

Not a lot in it, size-wise.

In my mind, the final scoring stacks up this way:

Fuji XF1 if you are a JPEG shooter and don’t plan to do much, or any, postprocessing.
Panasonic LX7/ Leica D-Lux6 if you shoot macro, or want to try and get some depth of field control.
Sony RX100 if you want the best image quality in any compact camera available, period.
Canon S110…I actually can’t think of any good reason to buy this – if you need GPS, perhaps.

The overall impression one gets of the XF1 is a positive one. It has some endearing quirks – the mechanical zoom, for the most part – some less endearing ones (control idiocy and mode confusion) – but what really impresses are the quality of the JPEGs. And if you need something pocketable that delivers great results without too much effort – albeit without as high ultimate image quality potential as something that has a malleable raw file – then this is probably the camera for you. In fact, I think it’s the perfect camera for my wife – she likes to have something responsive, compact and (sigh) stylish, can process RAW files but never bothers, yet is frustrated at the limitations of the JPEG output of most compacts. Just think of it as a tax to appease the other half before you tell them you’re buying a Hasselblad. MT

The Fuji Finepix XF1 is available here in several colors from B&H and Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: compact, finepix, fuji, gearhead, ming, ming thein, mingthein.com, review, thein, xf1

Mid term report: The Nikon D800E

October 27, 2012 By Ming Thein 182 Comments

I’d long ago intended to post a full review of the Nikon D800E, but somehow that got lost in a flurry of work, left-side AF problems, and repeatedly having to answer the question of ‘which camera should I buy?’ – note that this has now gotten even less straightforward now that the D600 is an option, too. And then there was the fact that it wasn’t really that different to the original D800, which I already reviewed here (I believe it was the first complete one up on the internet, actually). But now, I think enough time has passed, and I’ve used the camera under enough situations (and somewhere in the region of 20,000 images – almost all of them on-assignment) that I think it’s about time for a mid-term report card. This won’t follow the form of my historical reviews; rather it will take the form of a series of annotated comments. Some apply to both the D800 and D800E.

Apples. D800E, Zeiss ZF.2 2/100 Makro-Planar

One general observation is that it seems Nikon got the product mix wrong – most of the photographers I know bought the D800E over the D800, figuring that if they were going to go all out with resolution, they might as well really go for broke. I suspect this is contributing to the limited availability of the camera, despite the D800 being in stock – Nikon’s facilities were probably geared up to produce more D800s, but the demand is in favor of the D800E. I was recently told by NPS in Malaysia that while the D800 is readily available, the D800E is still back-ordered for a month or more.

I’m going to start with the bad first, to get all the negativity out of the way upfront.

Dragonfly. D800E, Zeiss ZF.2 2/100 Makro-Planar

Something still doesn’t feel right with the autofocus system.
Although my camera no longer exhibits any asymmetry with its focus points following the recalibration and fix by Nikon Malaysia, it just doesn’t seem to be as positive or accurate as the D700 was (or D600 is now). There are situations in which the camera nails everything perfectly, and situations under which it just seems to miss by a hair; far more of the latter exist than the former. And no combination of AF settings seems to work; this means that the D800 is effectively an unviable proposition to me as a documentary/ reportage camera. Bottom line: I’m not 100% confident that it’s going to focus where I tell it to.

Up or down? D800E, 28/1.8 G

The viewfinder is nearly useless for manual focusing.
Sure, it’s big and bright and covers 100% of the frame, but the problem is that it just doesn’t have enough focusing ‘snap’; it’s very difficult to tell when things are in critical focus or not, which is made doubly critical by the extremely high resolution of the sensor. It seems that all modern focusing screens are really just optimized for brightness with slow zooms. I would have done the same thing I did to my D700 – namely, cut and fit a custom screen from one of the other cameras I like – the F6 type J and FM3A type K3 are my favourites. However, the D800′s focusing screen is so enormous that this simply isn’t an option – I think it actually has the largest focusing screen of any Nikon to date, which means there are no suitable donors. I’m trying to get hold of an original screen to see if I can make it more matte on my own, perhaps by grinding it down with 1200 grit sandpaper. (You’re probably wondering how I use the camera at all without AF and a good finder – since most of my work with this camera is tripod-based anyway, live view comes to the rescue.)

The ZR012. D800E, 60/2.8 G Micro

Demands on lenses and technique are high.
It’s not the pixel density, but the pixel density for a given angle of view – this is the highest it’s been for any consumer/ prosumer level camera (i.e. non-medium format) to date. I think a lot of people confuse this with pixel pitch. The bottom line is that if your lens covers say 90 degrees horizontally, then the D800E puts much more resolving power per degree in the hands of the average photographer than they’re used to; this places corresponding demands on lens quality and technique (focusing, camera shake etc) than the vast majority people can manage handheld except under good light. I can’t even get a consistently sharp image unless I’m over 1/2x focal length – and I’m certain I’ve got better technique than average. This, and the size of the files (a throughput issue) make it impractical for a documentary/ travel/ journalism camera. Oh, and you’ve got to use good lenses too, which tend to be large and heavy – not ideal for walking around with.

Eleven. D800E, 28/1.8 G

The live view exposure implementation needs work.
If you shoot manual exposure, live view mode always shows you a preview of the actual exposure. Guess what this means if you’ve got things set up for a studio strobe exposure with zero ambient: a black frame! You’ll have to toggle back and forth between P and M modes to focus, which wastes time and is unnecessary – especially since they fixed this on the D600. I hope it’s something that gets addressed in a future firmware update. Or, at least give us an option…

Bored. D800E, 28-300VR

There are a few ergonomic fails.
The mode button is more and more annoying the more I use the camera – it’s just impossible to reach without contorting your grip, and muscle memory from using every other Nikon pro body means that you will almost inevitably try to change exposure with the video record button and back dial. The D-pad lock switch is too loose, and easy to activate, meaning that you may not be able to change focus point at a critical moment – and then be left wondering why, while your shot disappears. By a similar token, the metering mode switch is too stiff, and difficult to operate with the edge of your thumb. Aside from that, ergonomics are spot on. What I don’t understand is why Nikon seems to make minor changes between generations to both things that need fixing, and things that work fine as they are…

Polo. D800E, 28-300VR

The shutter appears to have a vibration issue around 1/30s or so.
I’ve noticed a strange blurring/ double image that occasionally pops up in the 1/20-1/40s range; even with everything locked down on a heavy – Gitzo 5 series systematic – tripod and studio lights; the only conclusion I can come to is that somewhere in the shutter or mirror mechanism, something is vibrating at that natural frequency and creating a bit of camera shake. The solution around this has been to use live view and the self timer when required; it of course doesn’t require the mirror to cycle.

3T MRI. D800E, Zeiss ZF.2 2.8/21 Distagon

File handling is…chunky.
This isn’t a flaw of the camera. But the increased amount of detail means even larger files than the D800; you’re looking at 40-50MB routinely for a compressed NEF. It would be a waste to shoot jpeg with this camera, of course. This is one of the reasons why I tell prospective buyers to think very, very carefully about whether they really need such large files: it has a knock-on effect on everything else from processing to storage. I usually open my raw files in batches; with the D700, my current laptop can happily handle 20; for M9, OM-D and RX100, it’s about 15; for the D800E…I think a threshold has been crossed somewhere, because it’s more like five.

Sarpaneva Korona K0. D800E, 85/2.8 PCE

Now for the good news:

Visible diffraction is offset somewhat by the lack of an AA filter.
My work requires small apertures on a regular basis; the diffraction limit for the D800 was visibly between f8 and f11, with all other things equal. The lack of an AA filter allows you to claw back some perceptual sharpness (though remember that diffraction is a property of the pixel pitch, and still sets in at the same point for both cameras) – all other things being equal, this allows a D800E image at f16 to have the same perceptual sharpness as a D800 one at f11 or thereabouts. Handy. Needless to say, at smaller apertures, the D800E provides a noticeably crisper image – there isn’t necessarily more resolution, but the pixel acuity is definitely higher.

All about the hair. D800E, Zeiss ZF.2 2/100 Makro-Planar

Moire is a non-issue for the majority of circumstances.
I don’t shoot a lot of fabrics or repeating patterns, but on the occasions I have done, I’ve seen very, very little moire. And these tend to be studio situations anyway, which means that I’m at small apertures; I can always have the option of removing any aliasing by stopping down a little bit more and letting diffraction take care of things for me should the situation arise. Conversely, I can’t add the acuity back to the D800′s files.

Jaeger-LeCoultre Master Ultra Thin Moon detail. D800E, 60/2.8 G Micro

Image quality is impeccable.
After working regularly with good D800E files, it makes me feel as though my other cameras are all lacking something; however, the knowledge that you really have to have all your ducks lined up in a row to make the D800E sing is enough for me to remain happy with the image quality from the rest. That said, the D800E is easily the best DSLR at the moment for any form of controlled lighting or tripod work; color accuracy and dynamic range are both superb; pixel acuity is beyond reproach (with the right lenses, of course) and – barring the aforementioned issues – usability is excellent.

Spiral. D800E, Zeiss ZF.2 2.8/21 Distagon

Battery life is outstanding.
Both the D800 and D800E have excellent battery life – easily 2000+ shots per charge without use of flash, or 1500+ if the built-in is used as a CLS trigger – which means that I only have one spare battery. This is a first for me: even my D3 had two spares. In fact, I think the real-world battery life of this camera is bested only by the D600.

Omega Speedmaster 9300. D800E, 85/2.8 PCE

It doesn’t feel that heavy.
Even though the camera isn’t much lighter than the D700, you do notice the difference after a day of shooting with it – my hands just don’t feel as tired as they did when I was using the D700. Perhaps it’s also a function of grip shape. I don’t know if this has negative consequences for camera shake and stability, though – probably not, since the D600 is even lighter and seems fine (though admittedly it also has a much lower-vibration and slower shutter).

How the other half live. D800E, 28/1.8 G

Overall, the impressions are good: very seldom is there a camera which I would consider perfect or close to it (the D700 was probably the last one) – the D800E pushes the image quality envelope forward by a significant margin, and with this necessarily comes compromises. The mistake I think most people make is in thinking that if you used the D700 with great results, you should be able to do the same with the D800E; no. Even for somebody who pays constant attention to shot discipline, you will find situations under which the demands of the sensor exceed your ability at that moment to achieve a pixel-level, critically sharp image. I know, because it’s happened to me several times.

This brings me to the final portion of this report card: I want to conclusively answer the ‘what should I buy?’ question once and for all.

Jaeger-LeCoultre Reverso Latitude. D800, 60/2.8 G Micro

Buy the D600 if:

Size and/or weight is a priority.
You are coming from a DX body that doesn’t have the same controls as the pro bodies (anything except the D2H/D2x/D300/D200)
You just want a general purpose FX body, and getting the large sensor ‘look’ is your priority.
You want resolution for large prints but can’t afford a D800E.
You shoot mostly handheld
You shoot a lot of live view work in the studio
You don’t print larger than 40×60″ or so

Buy a (or keep your) D700 if:

Budget is a priority – second hand D700s are abundant now, and cheaper than new D600s. They’re still capable of producing excellent images – I still use mine for reportage work.
You need speed or AF tracking ability – it has more coverage than the D600, and (I feel) higher precision than the D800E. It also runs at up to 8fps, which none of the others can.
You do a lot of low light or marginal shutter speed work – it’s just more forgiving for handholding.
You shoot in hostile environments
You don’t print larger than 20×30″ or so
Workflow throughput is a priority – events, weddings, sport etc.
You shoot mostly handheld
You don’t need video or live view

Buy the D800E if:

You need to have the absolute best image quality in a DSLR available now (due to lenses, or budget vs MF, or whatever)
You don’t mind using studio lights and/ or a tripod to maximize image quality
You don’t mind re-evaluating your lens lineup
You shoot a lot of video – it has manual exposure controls and power aperture than none of the other cameras do
You need to print larger than 60″ wide
You don’t mind (and have the hardware to) handle enormous files

Nadiah. D800E, 45/2.8 P

And what about the D800? Well, I honestly can’t see why anybody would bother unless money is super-critical, or you shoot a lot of fabric - the price difference to the D800E isn’t big enough to be a factor if you’re already committed to spending that much money, and it requires almost as much shot discipline and lens quality anyway. Finally, if you do a lot of long lens work – wildlife or similar – then you should probably look at a DX body instead; cropping isn’t going to up your frame rate much, or improve AF ability; the D600 and D700 probably won’t have enough resolution for demanding applications in DX crop mode, either.

I think what says the most about this camera is the fact that I only use it on assignment – it isn’t my first choice when I’m shooting personal work, or teaching (except in studio), or just going out for a while and feeling like I want to do some photography; something’s missing. And I don’t know if it’s the file sizes and processing that subconsciously puts me off, or something AF-related, or perhaps I’ve just moved on from feeling the need to carry a big camera for reassurance. Bottom line – I’m just not bonding with it in the same way I did with my D700, or even D2H for that matter – and those were even larger and heavier cameras. All of that said, I wouldn’t dream of using anything else for critical commercial work. MT

The Nikon D800E is available here from B&H and Amazon and the D600 here from B&H and Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Filed Under: Gearhead: Reviews Tagged With: d800e, equipment, gearhead, mid term report, ming, ming thein, mingthein.com, nikon, nikon d800e, review, thein

Quick review: The Olympus 15/8 Body Cap Lens

October 15, 2012 By Ming Thein 70 Comments

At left: body cap. At right: Lens. Not much difference.

Lens mounted on the E-LM5.

Disclaimer: if you came here looking for optical perfection, you should probably stop reading now.

On the other hand, if you came here because you were curious about this little pancake, then read on. I admit that although I’m usually squarely in the former category, for some odd reason, the 15/8 got me intrigued – I suppose it was the size, or the fact that it suits the whole ‘fun’ ethos of the smaller PEN cameras. I think it’s the photojournalist in me that very much likes the idea of having the camera ready to go at all times, even if it’s in storage; the Olympus BCL-15 lets you do just that. It’s effectively the same depth as the supplied standard body cap (maybe a millimetre or two thicker, but nobody’s counting) – making the smaller bodies like the E-PL5 and E-PM1 very pocketable indeed. The lens was launched together with a number of other items at Photokina 2012 – notably the E-PL5, E-PM1 Pens, 60/2.8 Macro and the wireless SD card system.

The mosque by the sea. E-PL5, 15/8

100% crops.

It isn’t anything special in terms of construction: the lens has just three elements (supposedly glass), all-plastic construction, and a clever little lever that both doubles as a shutter to protect the front element, as well as a focusing lever; on the subject of focusing, you can get as close as 30cm to your subject. The lever is light and doesn’t really stay in place if bumped, but then again, precision isn’t that important in a lens that both has an extremely great depth of field – being a 15mm f8 and all – and optics that aren’t exactly highly-corrected. In fact, it’s a wonder that it isn’t just fix-focused.

Book spirals. E-PL5, 15/8

100% crops.

Needless to say, there’s no electronic communication of any sort between camera and lens, so EXIF data is not recorded, and since there’s only one aperture, you’ve effectively got a point and shoot. Curiously though, it appears Olympus has put a small baffle between two of the elements to only use the central portion of the lens in a bid to keep image quality reasonably high; I suspect that if one could somehow separate the elements and remove this, you’d find the lens to be closer to f4 or thereabouts – at the expense of optical quality and depth of field, of course. It might be something I’d be willing to try as a rainy day project…

Staircase. E-PL5, 15/8

100% crops.

So how does it perform optically? Well, it’s surprisingly sharp in the center, even though the 16MP M4/3 sensors are already hitting diffraction limits at f5.6 and smaller; the lens might well be a bit sharper if it was a stop faster due to this. The edges and corners are another story – let’s just say they’re not very sharp anywhere, and rather smeary in places. No doubt this is due to the limited optical correction possible with just three non-aspherical elements. (That said, this lens reminds me of the MS-Optical Perar Triplet 35/3.5 and 28/4 lenses for the Leica M mount; I wonder how they perform optically.) So long as you keep your subjects in the central third or so of the the frame, and take a little time to ensure focus is just about at the right distance, optical results are better than expected.

Although you might think that some of the crops are soft because of the focus distance, let me assure you that at f8 and a 15mm real focal length, the depth of field is more than sufficient to cover where I placed the focal point – and that was verified with live view magnificaiton for the purposes of this test; in real life, I don’t think I’d bother.

Minaret. E-PL5, 15/8

100% crops.

Simple lens designs like this one tend to have very high contrast and transmission because there aren’t a lot of surfaces and air-glass interfaces inside the lens to lose light at; the 15/8 renders with very high macrocontrast indeed; microcontrast is much less impressive, though (and has a lot to do with resolving power – you weren’t surprised about that result, were you?). Color is saturated, brilliant and actually quite pleasing.

Sunset. E-PL5, 15/8

I can see photographers buying this for several reasons – as a fun walk around lens; as an impulse buy when you go to the camera shop with itchy fingers but perhaps not enough money or not finding anything that really catches your eye; the blogging crowd will probably find it fun and conveniently compact. I actually used it a lot while reviewing the E-PL5 (which all of these images were shot on) simply because it made the camera very pocketable and immediately responsive – not having AF and all – and being very close to my preferred 28mm focal length, an interesting street photography option (at least in good light; f8 means that you’re hitting ISO 3200 even in the shade, and forget about using it indoors).

Amusement park dusk. E-PL5, 15/8

Conclusion: At just US$60, it’s a no-brainer recommendation for anybody who owns a M4/3 camera, especially if you’ve got a older or spare one lying around. Mine now lives on my E-PM1 Pen Mini, which has seen little use since the OM-D and Sony RX100 entered the stable. put this on, stick the camera in your pocket, and go for a walk. You’ll be glad you did. MT

The Olympus BCL-15mm f8 Body Cap lens is available here from B&H or Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Abandoned, I. E-PL5, 15/8

Filed Under: Gearhead: Reviews Tagged With: 15/8, 15/8 body cap lens, gearhead, micro 4/3, micro four thirds, ming, ming thein, mingthein.com, olympus, review, thein

The Olympus E-PL5 PEN Lite review: a mini-OM-D

September 26, 2012 By Ming Thein 184 Comments

I make no secret of the fact that I’m a huge fan of the original Olympus E-PM1 Pen Mini (full review here); it brought big-camera speed and image quality to a very compact package. However, the OM-D clearly demonstrated that the image quality potential of Micro Four Thirds could be taken quite a bit further without entailing any compromises. After enjoying a period of exclusivity to that body, the same sensor and imaging processor has now made its way into Olympus’ lower end offerings – the E-PL5 Pen Lite and E-PM2 Pen Mini, both recently announced at Photokina. I was given the opportunity to try out a final production E-PL5 recently by Olympus Malaysia.

Removable grip.

The two cameras retain their original differentiation – a tilting screen and a few buttons. But the E-PL5′s screen now pivots through 170 degrees for self-portrait narcissists (I can’t personally imagine ever using this feature, though tilting it up for waist-level shooting is great for stealthy capture or a better angle without having to bend over). Both also gain the same capacitative touch screen capability of the E-P3 and OM-D, which I’m find increasingly useful and missing on my Nikons. Sadly though, the LCD on the two smaller cameras remains as a 3″, 16:9 aspect ratio unit, which is great for video but leaves a lot of unused real estate in the form of black bars when you’re shooting in the native 4:3 aspect ratio of the sensor. Useable area is probably closer to 2.5″.

Bookstore abstract. E-PL5, 15/8 body cap

Aside from the 15MP sensor of the OM-D, the E-PL5 also gains a few additional art filters, and compatibility with Olympus’ new OI.Share SD card and app for smartphones and tablets (currently, Apple iOS and Android are supported). There are also interchangeable grips – similar to the E-P3. There are also some minor cosmetic changes that give the camera a slightly blockier, more textured appearance. Personally, I prefer the smooth look of the older cameras. Sadly, Olympus still hasn’t moved the strap lugs – they still dig into your hands in the normal shooting position. I can’t help but feel a narrow loop would be a much better solution for a camera of this size, as well as being silent during video recording.

It’s grown in size a little, but it’s still roughly in the same ballpark as the original (and Pen Mini, in background.)

In use, the camera is snappy and responsive for all normal operations; AF speed remains excellent, if perhaps fractionally faster than the last generation. (I’m comparing it with my Pen Mini, since I don’t have an E-PL3 handy – they share the same innards anyway.) The menu system is redesigned and now looks very similar to the OM-D, complete with most of the custom functions and extensive customizability that is unusual for a camera in this class, which has become one of Olympus’ hallmarks. It also gains 8fps shooting, though without AF, of course. I use it as a single-shot camera, or at most in bursts of two or three shots to gain some added stability.

Closed for the weekend. E-PL5, 15/8 body cap

On the subject of stability, the in-body sensor-shift stailization system is improved over the last generation; I actually turned it off on my Pen Mini because it tended to give odd double images under some conditions. I left it on on the E-PL5, but it’s worth noting that it still isn’t as effective as the 5-axis gyro system in the OM-D.

Pirates can still be found in some parts of Malacca. E-PL5, 45/1.8

One of the things I missed from the OM-D was the configurable single-button magnify option that allowed one-touch enlargement of either live view or the playback image to your desired ratio at the focus point (10x is actual pixels) – until I discovered that you could just double-tap the screen to achieve the same result. Needless to say, score one for the touch screen. You can of course also use it to select the focus point and release the shutter; speaking of focus points, you can now select a smaller point size by default, which the camera remembers when turned off – something I sorely miss on the OM-D as the large boxes often aren’t precise enough. A good number of the other buttons are user-configurable, too.

Sunset over the straits. E-PL5, 15/8 body cap

Something I had trouble getting used to was the feel of the shutter button. Since it’s probably the single most important control on the camera, the way it feels is actually quite critical in how you feel towards shooting it; in this respect, the pro Nikons and Canons get it right – a soft but distinct half-press, and no clicky transition but a firm increase in resistance to release. There’s enough travel between positions to avoid accidental releases, but not so much to induce lag. The OM-D feels pretty good, too. Other cameras get it wrong – the Sony RX100′s shutter release is far too soft; I’m always accidentally firing off a frame when I meant only to focus. The digital Leica Ms are far too notchy and difficult to press smoothly; it’s as though there’s something rough inside the button’s housing or something; perhaps to do with the three positions. Shame, since the mechanical Ms were fantastic. Unfortunately, the E-PL5 just falls on the wrong side of soft – it isn’t so much the pressure required, but the near-zero difference in travel between half and full press that feels off. And to make things worse, even though the travel is short, the pressure required is very firm – making it difficult to hold the camera steady when releasing. Lack of an eye-level finder only compounds this.

Determination in the face of choices. E-PL5, 45/1.8

I don’t’ have a lot to say about image quality – if you’ve used the OM-D, you can safely skip this section. The files look exactly the same, and deliver the same amount of flexibility in postprocessing. Colors are typical Olympus – slightly warm, reasonably saturated, and biased towards delivery of very pleasing skin tones. Dynamic range is around 11-12 stops from a carefully processed raw file at base ISO, which also remains at 200. The tonal range tends to be somewhat midtone and shadow biased; the relatively small pixel pitch of the sensor makes itself known in the highlights; expose with care because there isn’t a whole load of recoverable headroom – perhaps a stop at most. Fortunately, there is a live shadow and highlight clipping display option, which allows for precise exposure adjustment at the time of capture. Noise is minimal to ISO 800, and I feel the camera is useable up to ISO 3200, or ISO 5000 under certain lighting conditions.

Just your average chaotic street scene. E-PL5, 45/1.8

At this point it’s worth talking a bit about the Olympus Viewer software – I’ve never had to use it before since ACR always supported the files of cameras I’d purchased. This time, I use the built in raw converter to make a relatively low-contrast TIFF with accurate white balance and exposure, which I’d then take into Photoshop. The native environment is very familiar – it looks a lot like Bridge, from which you can develop and save your files in…you guessed it, something that looks a lot like ACR – or at least an early version of it, without the huge number of options the current version has.

Late afternoon. E-PL5, 15/8 body cap

Previews are fast, and general responsiveness and usability was good. This is easily amongst the better own-brand pieces of software out there. (Nikon, I’m looking at you. For shame.) In fact, the only critical things I can find missing are shadow/ highlight recovery sliders and a gradient tool. I’m not so happy with the output, though – the files seem to have a decidedly magenta cast to them which is both difficult to remove, and renders color not as accurately as the JPEGs – especially skin tones, which I find my Olympus cameras generally excel at even via ACR.

Harley after the rain. E-PL5, 45/1.8

Battery life is excellent; I estimate around 500-600 shots with moderate LCD use and power-off between shots. It uses the same battery as the E-PL3 and E-PM1, too, which is nice if you’ve got a few spares already lying around. Note that there are two models of battery and charger, some of which are compatible and some of which aren’t – the light gray model is the latest version of both.

Where Elmo does his shopping. E-PL5, 45/1.8

Throughout the review period, I kept asking myself who this camera was aimed at; the DSLR user/ enthusiast/ amateur looking for a second, more compact body, or the compact upgrader? I personally think it fits the latter better, much like the original Pen Mini. Although it’s compatible with the various accessories that connect to the accessory port under the hotshoe (including an EVF) – the lack of a built-in viewfinder means that if youre going to keep the camera compact, you’re restricted to arms-length style shooting. The huge number of art filters – also useable in movie mode at the expense of reduced frame rate – and in-camera processing options offers a relatively simple (if slightly lacking in control) method for the amateur user to achieve their desired look without resorting to Photoshop. I personally don’t use any of these, but I do know plenty of friends and family who might. What I did really enjoy was using it with the new 15/8 body cap lens as a hyperfocal snapshot camera; in this configuration it’s lag-free, and lets you focus solely on timing and composition. It’s also just about pocketable.

Ultimately, success at this end of the market will depend heavily on the camera’s price point. The rich feature set and overall refinement in operation make me curious to see what will succeed the E-P3; now if only they’d make one with a built-in EVF like the NEX-6…

The Olympus E-PL5 PEN Lite is available here from B&H and Amazon.

____________

Visit our Teaching Store to up your photographic game – including Photoshop Workflow DVDs and customized Email School of Photography; or go mobile with the Photography Compendium for iPad. You can also get your gear from B&H and Amazon. Prices are the same as normal, however a small portion of your purchase value is referred back to me. Thanks!

Don’t forget to like us on Facebook and join the reader Flickr group!

Where are my customers? E-PL5, 45/1.8

Somewhere in here is a human being. E-PL5, 45/1.8

Abstract Kuala Lumpur skyline. E-PL5, 15/8 body cap

Filed Under: Gearhead: Reviews Tagged With: e-pl5, gearhead, micro 4/3, micro four thirds, ming, ming thein, mingthein.com, olympus, pen, pen lite, pen lite e-pl5, thein

Review: The Leica D-Lux 6/ Panasonic LX7

Lens review: The Leica 35/1.4 Summilux-M ASPH FLE

The 2013 Leica M Typ 240

Review: The Ricoh GR1v

Review: The Contax T3

Quick review: CarrySpeed DS-2 sling strap

Lens review: The Nikon AFS 60/2.8 G Micro

Lens review: The Olympus ZD 12/2

Lens review: The Voigtlander Color-Skopar 28/2.8 AI-P SLII

Twenty questions

Lens review: The Nikon AF-S 85/1.8 G

Review: The Fuji FinePix XF1

Mid term report: The Nikon D800E

Quick review: The Olympus 15/8 Body Cap Lens

The Olympus E-PL5 PEN Lite review: a mini-OM-D

Ming Thein’s Photography Compendium for iPad

The recommended equipment list

Announcements and news

Popular recent posts

Twitter Updates

Follow “Ming Thein | Photographer”

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Knowledge is for sharing:

Like this:

Ming Thein’s Photography Compendium for iPad

The recommended equipment list

Announcements and news

Popular recent posts

Follow “Ming Thein | Photographer”
